High Quality 400bar Ceramic pressure sensor differential pressure gauge for test instruments Pressure Transducer Transmitter

No.HXL200CXH13
HXL200CXH13 of transmitters are pressure products fully independently developed by Huaxinlian, utilizing self-developed ceramic cores. These products boast high temperature resistance, corrosion resistance, high stability, and high reliability. With a compact size, superior overall performance, and high cost-effectiveness, they are suitable for industrial liquid and gas measurement, as well as applications in water treatment, food and chemical processing, medical and pharmaceutical manufacturing, automation, process control, and other fields. Every process in our production chain, from research and development, production assembly, calibration, to quality inspection, is strictly implemented according to international standards for product quality and production systems.
  • High Quality 400bar Ceramic pressure sensor differential pressure gauge for test instruments Pressure Transducer Transmitter
  • High Quality 400bar Ceramic pressure sensor differential pressure gauge for test instruments Pressure Transducer Transmitter
  • High Quality 400bar Ceramic pressure sensor differential pressure gauge for test instruments Pressure Transducer Transmitter
  • High Quality 400bar Ceramic pressure sensor differential pressure gauge for test instruments Pressure Transducer Transmitter
  • High Quality 400bar Ceramic pressure sensor differential pressure gauge for test instruments Pressure Transducer Transmitter
  • High Quality 400bar Ceramic pressure sensor differential pressure gauge for test instruments Pressure Transducer Transmitter

Main Features

Product features
* Resistant to high and low temperatures,from -20℃ to 85℃
* Compact structure with excellent cost-performance ratio
* Algorithm compensation and correction technology
* Multiple signal outputs
* 150% F.S overload protection performance, strong impact resistance
* Supports customization of various specifications.

Product Parameters
Measuring range
-1-0-1…400 bar
Pressure type
Gauge/Negative/Absolute pressure optional
Material
SUS304 stainless steel, 316L stainless steel, copper, customization
Sensor
Ceramic (Standard)
Accuracy
≤ ±0.50%F.S.(Routine);≤ ±1%F.S;Customizable Accuracy
Overload Pressure
150%F.S.
Burst Pressure
300%F.S.
Working Temp
-30℃~85℃
Storage Temp
-30℃~85℃
Output
4~20mA
0~5V
0~10V
0.5~4.5V
Power supply
8~32V DC
8~32V DC
12~32V DC
8~32V DC/5V DC
Electronicl connection
Packard connector、Straight connection
Pressure connector
1/4" NPT, R1/4, G1/4", G1/2", M14×1.5, M16×1.5, M20×1.5, Customizable



FAQ
Q1: Are your company's products manufactured in-house? Is it a factory?
A: Yes, we have a fully automated production facility of over 3,000 square meters in Jiangxi.

Q2: What is the production capacity of the factory?
A: We produce up to 300,000 sets per month.

Q3: What is your typical lead time for delivery?
A: It ranges from 3 days to 30 days, depending on the order quantity and specific requirements.

Q4: What are the advantages of your products? How do they differ from others?
A: Our products have excellent consistency in quality due to our fully automated production lines, achieving a comprehensive TEB accuracy of up to 0.5%.

Q5: Do you have any R&D patents?
A: Yes, we have 25 proprietary patent applications, including 9 national patents.

Q6: Are your products specifically for gauge pressure?
A: We offer gauge pressure, absolute pressure, and sealed gauge pressure products.

Q7: Do you have quality guarantee?
A: Yes we have 12 months quality guarantee.

Q8: What is the operating temperature range for your ceramic pressure transmitter?
A: The operating temperature ranges from -30 to 85°C.

Q9: What output signal do you have?
A: We have current/voltage output as well as digital output.
